Product Details:
Payment & Shipping Terms:
|
Material: | Q235B Or Q345B | Wall: | Glass Curtain Wall |
---|---|---|---|
Roof: | Waterproof Panels | Main Frame: | Assembly With H Shape Beam And Column.etc |
Steel Purlin: | C Purlin , Ceiling ,Tie Bar .etc | Surface Treatment: | Painted And Hot Galvanized And Customized |
Color: | Customized | Standard: | China GB ,US,EU,AUS,NZ .etc. |
High Light: | Zealand Standard Multi Storey Apartment,Zealand Standard Modular Steel Building |
Introduction:
Steel structure apartment building has features of high fire resistance, strong corrosion resistance. Steel structure building is mainly refers to the main bearing component is composed of steel. Including the steel columns, steel beam, steel structure, steel roof truss.Each component using welds, bolts or rivets to connect.
The roof and wall can be made of composite panel or veneer. Galvanized sheet metal can prevent rust and corrosion. The use of self-tapping screw can make the connection between the plates more closely, to prevent leakage. You can also use composite panel for roof and wall. The sandwich is polystyrene, glass fiber, rock wool, polyurethane. They have good thermal insulation, heat insulation, fire-retardant. The wall of the steel structure maintenance also can use brick wall. The cost of a brick wall is higher than galvanized steel roof and wall.
The usage scale includes large-scale workshop, or warehouse, supermarkets, entertainment centers and modular steel structure garage.
Specification:
Material: | specification: |
Length | As customer's requirement |
Width | As customer's requirement |
Height | As customer's requirement |
Column | H shaped,Q345 |
Beam | H shaped,Q345 |
Purline | C/Z shaped,Q235/Q345 |
Brace | Round bar,Q235 |
Knee brace | Steel angle,Q235 |
Tie bar | Steel round tube,Q235 |
Roof panel | single steel sheet /sandwich panel/UPVC Panel |
Wall panel | single steel sheet /sandwich panel/UPVC Panel |
Gutter | 0.8mm steel sheet/1.2mm steel sheet/3mm steel sheet |
Rain Pipe |
DN110mm PVC rain pipe
|
Features
1. The structure adopt high quality H type, C type, Z type steel.
2. Walls and roof are made up with superior sandwich panel, such as: EPS, PU, Glass wool, Rock wool.
3. Less material to install, more convenient and environmental protection.
4. Different colors can be chosen, more concise and beautiful appearance.
Advantages:
1 . Seismic resistance: grade 8
2 . Wind load: grade 8
3. Fast & easy construction: 4 workers can finish about 60sqm in 8 hours.
4 . Long life span: 15-25 years
5 . Advanced heat insulation & preservation mode
6 . Eco-friendly, Energy-saving
7 . Excellent sound-proof, water-proof, fire-proof
8 . Suit for all kinds of climatic zone
9 . Custom-made service is provided.
Application
Our experience in steel framed industrial buildings is extensive and includes the design and construction of many different steel framed structures including:
• Textile Factories on our building steel site
• Process Plants on our building steel site
• Waste Transfer Stations on our building steel site
Packing & Delivery
1. All the materials are well packed by the plywood or the steel skid before loading the container.
2. All the materials are well fixed and tight to prevent the moving during the transport.
3. Loading plan will be designed before the materials loading to utilize the loading space and reduce the shipping cost.
