Customized Cold Chamber Freezer Room For Seafood Storage Walk In Cooler Panels For Commercial Industry
Payment & Shipping Terms:
|Kind:||Cold Room Panels||Thickness:||100mm|
|Density:||10kg||Used For:||Cold Room|
|Panel Material:||Steel Sheet||Surface Treatment:||Galvanized|
|Core Material:||Polystyrene||Effective Width:||950mm|
modular cold rooms,
cold storage freezer
Cold Room PU(Polyurethane) Thermal Insulated Panels
Easy assembly and disassembly top quality steel plate cold storage for frozen food
PR Size of the plan of the Polyurethane (PU) Panel:Specifications, to meet the different requirements of customers. Characterized as follows: thermal insulation performance, light weight, high strength, corrosion-resistant, anti-aging, beautiful appearance.
Polyurethane Panel: Polyurethane (PU) panel ( insulated panel),the sandwich board rigid polyurethane (PU) foam high pressure, both inside and outside the metal surface layer, the option of color-coated steel plate, PPGI ,embossed aluminum, stainless steel plate and galvanized steel and other materials,PU cold storage is generally modular cold storage, from polyurethane base plate using advanced eccentric rotary combination lock to ensure that the cold intensity.
1. Modular insulation panel, CAM hook, Installation is simple, easy to install
2. Refrigeration: R22, R404A, Glycol Secondary Refrigerant
3. Temperature Range: From - 30°C To + 22°C
4. Room Size: According to the customer request design
5. Functions: Keep Fresh, Frozen, Quick-Freeze, Fire-Proof
|Cold Room Polyurethane ( PU) Sandwich Panels|
|Thickness||50, 75, 100, 150 , 200 mm|
|Density||38 - 40 – 43 – 46 kg / m3|
|Joint||Camlock (tongue and groove)|
|Plate||External is color steel or stainless steel or Aluminium (Stucco embossed or pre-painted)|
|Usage||Wall & Floor & Ceiling|
|Door||Sliding door and Swing door|
DETAILS OF THE PANEL JOINT
Cold room door panels are joined together by means of tongue and groove and locked together by camlock on each side of the panel to ensure air tight joints.
* Cam-lock design fastener to install with the cold room tightly and strongly
* Silica gel are used on the cold room door panel edge of the joint parts of each sandwich panel to ensure perfect sealing to avoid the cooling air leakage from the cool roomor moisture inside the PU insulated panel for the best refrigeration and frozen storage result
Walk in freezer Size and temperature can be made according to the customers' requirements
0 °C ~ + 22°C: Communication Station, Mushroom Plant, Medicines Storage, Processing Room, Packing Room
-5 °C ~ + 5 °C: Pre-Cooling, Keep Fresh,
-10 °C ~ -20 °C: Freezer Storage
-25 °C ~ -30 °C: Low Temperature Storage, Quick-Freeze
-35 °C ~ -50 °C: Blast Freezer, Quick-Freezer
1). Swing door and Sliding door available.
2). Swing door: Manual, Automatic available etc.
3). Door panel made with special pressing technology PU material.
4). Door frame: color steel or stainless steel.
5). With Heater and anti-stuck system.
Hinged doors are of various types such as single leaf or double leaf , overlapping or flush . These doors are
always open in the outward direction towards either left or the right .
