Automated Aluminum Can Production Line for Aerosol Cans

Name: Automated Aluminum Can Production Line for Aerosol Cans
Brand: FAMOUS Steel Engineering Company
SKU: AM01
Price: 550,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: FAMOUS

Model Number: AM01

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: $100000-1000000

Delivery Time: 10-12 months

Payment Terms: L/C, T/T, D/P

Get Best Price

Product Details

Product Description

Highlight:
                                                automated aluminum can production line, aerosol can forming machine, cold roll forming machine for cans


Automated Aluminum Can Production Line for Aerosol Cans

Product Overview

Our aluminum aerosol can production line is a turnkey solution for producing high-quality aerosol cans efficiently and reliably. It covers every step — from blank extrusion to the final printed and finished cans — ensuring stable performance and excellent output.

Key Features & Benefits:
✅ Turnkey Solution: From aluminum extrusion to finished cans.
✅ High Efficiency: Annual capacity 30M–100M cans with ≤0.5% defect rate.
✅ Energy Saving: Servo-driven systems reduce power consumption by 20–30%.
✅ Compliance: Meets ISO9001, FDA (food/medical grade optional).

Technical Parameters:
* Material: 1000/3000 series aluminum.
* Can Sizes: 45–76mm diameter, 50–300mm height.
* Power: 380V/50Hz (customizable).
* Automation Level: PLC + HMI (Allen Bradley/Siemens optional).

PRODUCT SPECIFICATIONS

No	Machine Name	Key Function	Technical Highlights
1	Extrusion Press Machine	Forms aluminum slugs into precise cups	±0.01mm tolerance, servo-driven, 1M+ mold cycles
2	Trimming Machine	Trims cup edges to uniform height	Automatic scrap recycling, adjustable speed
3	Washing Machine	Removes oil and contaminants (3-stage cleaning)	Alkaline → acid → DI water, FDA-compliant
4	Accumulator	Balances production flow between stations	Reduces downtime by 15–20%
5	Internal Coating Machine	Applies corrosion-resistant epoxy coating inside cans	FDA-approved materials, spray precision ±2µm
6	Lacquer Curing Machine	Dries/cures internal coating (UV or thermal)	±2°C temp control, energy-efficient
7	Base Coating Machine	Applies primer for print adhesion	Uniform layer, quick-drying
8	Printing Machine	Adds logos/designs (flexographic or digital)	6–8 colors, 1200 dpi resolution
9	Varnish Machine	Applies protective gloss/matte finish	Scratch-resistant, customizable
10	Drying Oven	Dries printed/varnished cans	Multi-zone IR heating, adjustable length
11	Necking Machine	Forms threaded necks (2–3 stages)	Precision: ±0.05mm, servo-controlled
