Insulated Cold Room Panels For Cold Chamber Freezer With Whole Cooling Unit

Large Image : Insulated Cold Room Panels For Cold Chamber Freezer With Whole Cooling Unit

Product Details:

Place of Origin:	Mainland of China
Brand Name:	FAMOUS
Certification:	CE,ISO9001,SASO,SGS
Model Number:	960mm & 1180mm

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD1500/ set
Packaging Details:	Standard seaworthy packing
Delivery Time:	within 20-30days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5000 sets per month

Contact Now

Detailed Product Description

Power:	5kw-200kw	Refrigerating Unit:	, Copeland Compressor, Evaporator, Condensor Etc.
Cooling Approach:	Water Cooled Or Air Cooled	Functions:	Fresh Keeping ,freezing ,air Conditioning
High Light:	modular cold rooms , cold storage freezer

Power:

5kw-200kw

Refrigerating Unit:

, Copeland Compressor, Evaporator, Condensor Etc.

Cooling Approach:

Water Cooled Or Air Cooled

Functions:

Fresh Keeping ,freezing ,air Conditioning

High Light:

modular cold rooms

cold storage freezer

Insulated cold room panels for cold chamber freezer with whole cooling unit

1. Machine Parts

(1) Condensing unit: , Copeland, Maneurope (Danfoss), Yemoo,etc.
(2) High efficiency air-coolers
(3) Insulation Panel: PU panel
(4) Other accessories: world-famous brands, like Danfoss, Castle, Electric Control: Siemens, Schneider, CHNT, etc.

2. Electric controlling system:

Schneider electric components, digital display for temperature setting and reading, automatic and manual control, warning light for running failure.

3. PU Insulation panel, cold store panels:

3.1 Material: polyurethane (PU), metal sheet.

3.2 Density of PU: 35~42kg/m3

3.3 Metal sheet:according to requirements

3.4 Thickness of panel: 50mm,75mm,100mm,120mm,150mm,200mm

4. Cold store door, air curtain machine, lighting:

4.1 Sliding door, manual opening and closing.

4.2 When door is opened, the air curtain machine and lights in cold storage can be running automatically.

Insulated Cold Room Panels For Cold Chamber Freezer With Whole Cooling Unit 0

Item	Cold room
Voltage(V)	380V/50Hz-3P, 380V/60Hz, 220V/50Hz, 220V/60Hz optional
Cooling model	Air cooled / water cooled / evaporation cooled
Compressor	Original new American copeland, Germany etc
Refrigerant	R404A, R22
Dimension(M)	Room size(LWH) can be customized
Panel Material	PU panel, 42 kg/m3 density
Panel Thickness	100mm, 120mm, 150mm, etc
Steel Plate Thickness	0.5mm/0.6mm
Cold Room Doors	Hinged door, Sliding door, double swing door etc
Cold Room Door Size	0.8*1.8 meters, door size can be customized
Temp Controller	Elitech, Dixell thermostat
Defrost Type	Electric defrosting
Capacity	3CBM~5000CBM
Applications	Storage Meat, vegetable, Food, Sea Food, Fish, fruits etc

DOORS

1). Swing door and Sliding door available.
2). Swing door: Manual, Automatic available etc.
3). Door panel made with special pressing technology PU material.
4). Door frame: color steel or stainless steel.
5). With Heater and anti-stuck system.

Hinged doors are of various types such as single leaf or double leaf , overlapping or flush . These doors are
always open in the outward direction towards either left or the right .

For any quote, please reply the questions below,

1. What is your cold storage room used for, food, vegetable, meat, ice or others?
2. What is your required room temperature?
3. What is the cold storage room dimension, length, width, height?
4. This projects will build in which country ? Whats the temp in summer over there?
5. Do you need the refrigerator systems from us, or you will buy from local market?
