Payment & Shipping Terms:
|Thickness:||50mm, 100mm, 150mm, 200mm||Density:||40kg/m3|
|Used For:||Fruit,Vegetables,Seafood,Meat Storage, Dairy Products,Drug Processing Plant||Effective Width:||950mm|
|Color:||Customized||Core Material:||PU Sandwich Panel|
commercial walk in freezer,
walk in refrigerator
Freezer Room and Fresh Cold Storage Rooms With Good Heat Insulation Assembled By Polyurethane(PU) Sandwich Panels
ABOUT THE GROUP
Hangzhou FAMOUS Steel Engineering Co.,Ltd. focus on various structural steel construction and steel-related products supplying. Under support of structural giant Hongfeng Industrial Group, FAMOUS received a lot of foreign projects from project engineering, fabrication, logistic and installation guidance etc. and become more professional in foreign project operation, specially in US-EU standard engineering and project management aspects. The company covers an area of 360,000 sq.m. with registered capital of 100 million Yuan and the total assets of 970
million Yuan. It owns advanced professional production equipment for the all automation production line of H type that is most advanced at home, pipe truss structure, boxbeam production lines, CNC hydraulic punching posterior cutting C type steel weather board production lines and metal sandwich panel production lines, etc.
PU sandwich panels is a kind of board used for enclosing structures, which has good heat insulationand higher intensity.It can reduce the heat transmission caused by difference in the internal and external temperature, and get to maximum efficiency of freezing and refrigeration systems.
Designed scientifically and easy to use. It is a new type of heat insulation material for lower construction cost.Panels are in multiple varieties and specifications to meet the need of various sites and projects.
|Cold Room Polyurethane ( PU) Sandwich Panels|
|Thickness||50, 75, 100, 150 , 200 mm|
|Density||38 - 40 – 43 – 46 kg / m3|
|Joint||Camlock (tongue and groove)|
|Plate||External is color steel or stainless steel or Aluminium (Stucco embossed or pre-painted)|
|Usage||Wall & Floor & Ceiling|
|Door||Sliding door and Swing door|
Size : All the panels produced by us are discontinuous type and locked to each other. These panels can be produced 50 cm, 100mm and 150mm, widths are 980mm in standard or customized, Installation details and accessories of the prefabricated panels are predesigned, and outer surfaces can be produced with painted and galvanized metal sheets, or stainless steel metal sheets.
1. Broad Availability ,wide range of material for your choice
2. Outstanding Formability with beautiful appearance with rich color
3. Superior Durability
4. Excellent Cost Effectiveness
5. Light weight , easy to transportation ,easy to install
Walk in freezer Size and temperature can be made according to the customers' requirements
0 °C ~ + 22°C: Communication Station, Mushroom Plant, Medicines Storage, Processing Room, Packing Room
-5 °C ~ + 5 °C: Pre-Cooling, Keep Fresh,
-10 °C ~ -20 °C: Freezer Storage
-25 °C ~ -30 °C: Low Temperature Storage, Quick-Freeze
-35 °C ~ -50 °C: Blast Freezer, Quick-Freezer
DETAILS OF THE PANEL JOINT
Cold room door panels are joined together by means of tongue and groove and locked together by camlock on each side of the panel to ensure air tight joints.
* Cam-lock design fastener to install with the cold room tightly and strongly
* Silica gel are used on the cold room door panel edge of the joint parts of each sandwich panel to ensure perfect sealing to avoid the cooling air leakage from the cool roomor moisture inside the PU insulated panel for the best refrigeration and frozen storage result
1). Swing door and Sliding door available.
2). Swing door: Manual, Automatic available etc.
3). Door panel made with special pressing technology PU material.
4). Door frame: color steel or stainless steel.
Sandwich panels are used in facades, partition walls and ceilings. The most typical applications include industrial, office and commercial buildings, sports halls, warehouses and power plants. The panels are also suitable for food industry construction and demanding clean room applications.
Energy saving: PU sandwich panel insulation system is a comprehensive external wall system that ensures an extremely low air leakage for your building, to reduce heating energy needs and helps improve its energy rating.
