PU Cold Room Insulated Sandwich Panels

China PU Cold Room Insulated Sandwich Panels supplier
PU Cold Room Insulated Sandwich Panels supplier PU Cold Room Insulated Sandwich Panels supplier

Large Image :  PU Cold Room Insulated Sandwich Panels

Product Details:

Place of Origin: China Mainland
Brand Name: HongFeng
Certification: ISO,SGS,CE,COC,etc.
Model Number: HF950mm

Payment & Shipping Terms:

Minimum Order Quantity: 100 Square Meters
Price: 10-21USD Per Square Meter
Packaging Details: Standard seaworthy packing
Delivery Time: 7-15Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 200,000 Square Meters per Month
Detailed Product Description
Core Material: Polyurethane Fire Retardant: PU Material
Effective Width: 950mm Application: Warehouse Or Plant
Length: Customized Surface Color: Blue & Red & White Grey
Treatment: Galvanized And Color Coated Function: Thermal Insulation
High Light:

eps sandwich panel

,

corrugated metal roofing sheets

Sandwich panels with polyurethane(PU) core

PU Cold Room Insulated Sandwich Panels 0

FEATURE



High thermal insulating power

High Durability of Anti-corrosion Coatings

Solid and Durable

Easy Assembly and Low Weight

Aesthetic Appearance

Fire Resistant



APPLICATION



Exterior and Partition Walls

Structure Insulation

Industrial and Commercial Facilities

Agricultural Facilities



TECHNICAL PARAMETERS



Steel Thickness

0.3mm-0.8mm

Panel thickness

50/75/100/120/150/200 mm

Effective width

(1) 950/mm ---for roof

(2) 950/1150mm ---for wall or ceiling

Length

According to customer's request

Materials

Inner is EPS/PU/Rockwool, two sides is Color steel sheet

Structure

three layers:

(1)upper layer is steel sheet,

(2)the inner layer is EPS/PU/Rockwool sandwich,

(3)the bottom layer is also steel sheet

density

32-20(kg/m³),etc

color

blue, white grey, red,or other colors .

Parts

Steel line for easy connect one by one

Film covering in order to protect the steel of panels

lifetime

15~20 years

Character

Light in weight, heat insulation, fireproof and water proof, environmental

Use

various roofs and walls referring to the large size factory buildings, storages,

exhibition halls, gymnasiums ,etc

Packing

standard seaworthy packing or according to your demands





DETAILS OF THE PANEL JOINT





PU Cold Room Insulated Sandwich Panels 1



SECTIONAL VIEW OF THE PANELS



v      Thermal insulation

Advanced way of external thermal insulation puts an end to hot and cold bridge phenomenon,

so that the buildings can be protected from the damp deformation, mildew, corrosion, and so on.

v      Windproof

Having a resistance of 12 degree typhoon because of thefirm connection

of basic parts (roof, floor and wall) by special accessory.

v      House bearing and Fireproof

The roof snow load can meet the snow load requirements of 1.5m with optional designs according

to the climate condition.

v      Sound insulation and Noise reduction

With perfect sound insulation and shock absorption, it meets the national standard of building sound insulation.

v      Energy-saving and eco-friendly

Energy saving, water saving, material saving, land saving and eco-friendly.



PU Cold Room Insulated Sandwich Panels 2

PU Cold Room Insulated Sandwich Panels 3



ASSEMBLY INSTRUCTION



Sandwich panels are used in facades, partition walls and ceilings. The most typical applications include industrial, office and commercial buildings, sports halls, warehouses and power plants. The panels are also suitable for food industry construction and demanding clean room applications.



Sandwich panels are cost-efficient prefabricated elements that consists of an inner insulation core between two colour-coated steel sheet layers. The insulating core can be mineral wool, polyurethane, polyisocyanurate or polystyrene.PU Cold Room Insulated Sandwich Panels 4

THE TRANSPORT



PU Cold Room Insulated Sandwich Panels 5





AFTER-SALE SERVICES



In addition to sandwich panels, FAMOUS Steel offers a wide range of steel construction materials and tools needed for their installation. We also provide a comprehensive selection of professional services and full technical support of steel structure .



Design and installation services are an important part of FAMOUS’s sandwich panel offering package with a view to speeding up our customers' projects.



12 hours feedback , 24 hours solution .
