Product Details
Place of Origin: Zhejiang, China
Brand Name: HONFENG
Certification: ISO9001:2008
Model Number: OWN
Payment & Shipping Terms
Minimum Order Quantity: 100 Square Meter
Price: USD6~USD15 per Square Meter
Packaging Details: Seaworthy packings into container or bulk vessel
Delivery Time: Based on client's needs
Payment Terms: L/C,T/T
Supply Ability: 200,000 Square Meter per Month
Core Material: |
Polystyrene |
Core Material Thickness: |
50mm |
Density: |
11kg |
Steel Thickness: |
0.35mm |
Steel Color: |
Grey |
Effective Width: |
970mm |
Core Material: |
Polystyrene |
Core Material Thickness: |
50mm |
Density: |
11kg |
Steel Thickness: |
0.35mm |
Steel Color: |
Grey |
Effective Width: |
970mm |
EPS Panel
Semi-fireproof material, flame retardant material EPS Panel
Kwang Steel’s cap panel product, which uses semi-fireproof, phenol resin,
and foaming polystyrene, is not burnt in fire.
Fire insurers laboratories of Korea recognized Kwang Steel cap panel, which passed
strict fire test, as fire safety product.
Perfect water proof: Surface waterproof function is excellent and it shows excellent
waterproof and humidity proof effect rainy season.
Excellent economical efficiency: EPS Panel is economic because of product's standardization,
quick construction and labor free reduction.
Sanitary environment : EPS Panel's surface is the zinc galvanized steel plate painted with
fluorine or silicon polyester, which creates sanitary environment because it can be easily cleaned
up.
Advantages :
1 Easy for installation
2 Thermal Insulated
3 Light Weight
4 Repeated use
5 water resistant
|
950mm wall sandwich panel & 970mm roof sandwich panel |
||
|
Type |
EPS sandwich panel (self- insert connection) All the screw and accessories are available |
|
|
Dimensions |
Total thickness |
50,75,100,120,150,200mm |
|
Width |
950mm / 970mm / 1150mm |
|
|
Length |
Less than 11.8m |
|
|
External face |
Material |
ppgi |
|
Thickness |
0.3-0.8mm |
|
|
Thickness of the zinc |
80g/m2 |
|
|
Corrosion protection |
Galvanized |
|
|
Coating |
Polyester |
|
|
Thickness of coating |
20 micron |
|
|
Color |
According to the RAL |
|
|
Pattern |
Nearly Plain |
|
|
Insulation |
Material |
EPS |
|
Thickness |
50,75,100,120,150,200mm |
|
|
Density |
6-24kg/m3 |
|
|
Thermal conductivity |
0.02~0.03w/mk |
|
|
Internal face |
Material |
ppgi |
|
thickness |
0.18-0.9mm |
|
|
Thickness of zinc |
80g/m2 |
|
|
Corrosion protection |
Galvanized |
|
|
Coating |
Polyester |
|
|
Thickness of coating |
7micron |
|
|
Pattern |
Plain |
|
|
Shipping terms |
||
|
Package |
|
|
|
Delivery time |
Within 5-10 days after your prepaid |
|
|
|
|
|
|
Payment terms |
T/T ,L/C at sight |
|
