Product Details:
Payment & Shipping Terms:
|
| Features: | Shoring/proping/bracing/support | Name: | Steel Bracing Alignment System |
|---|---|---|---|
| Core Material: | Steel | Length: | 1600mm |
| Color: | Galvanized | Weight: | 30kgs |
| Application: | Protective Support Bracket | Gauge: | 11/13/14 |
| High Light: | Steel Bracing Alignment System,Customized Bracing Alignment System,Turnbuckle Bracing Alignment System |
||
Insulated concrete form (ICF) installers must master the installation of the ICF wall alignment bracing system to ensure the success of the ICF wall project. ICF bracing systems align the wall before pouring the concrete. ICF bracing also allows the installer to plumb the walls immediately after pouring the concrete. The bracing system is critical as it protects the poured wall from wind and other lateral loads until the concrete has fully cured. A properly applied ICF bracing system ensures worker safety, as well as straight, level, and plumb ICF walls.
The spacing of ICF bracing should achieve the following:
Align the ICF walls
Withstand wind loads on the ICF wall
Prevent leaning walls
Withstand concrete pressures during the pour
Accommodate the lengths of scaffolding planks
The areas near the door and window openings, on the corners, and the T-intersections may require extra bracing.
| Product Name | ICFs Bracing System |
| Dimension | 3000mm |
| Shape | Rectangle |
| Weight | 30kgs |
| Pin | 3pcs |
| EPS Density | 30-45kg/m³ or customized |
| Energy saving | 90% |
| Application | standard tool for building Support |
| MOQ | 50pieces |
