Prefabricated Luxury Mobile Steel Container House Aluminum Profile For Office Building

China Prefabricated Luxury Mobile Steel Container House Aluminum Profile For Office Building supplier
Prefabricated Luxury Mobile Steel Container House Aluminum Profile For Office Building supplier Prefabricated Luxury Mobile Steel Container House Aluminum Profile For Office Building supplier Prefabricated Luxury Mobile Steel Container House Aluminum Profile For Office Building supplier

Large Image :  Prefabricated Luxury Mobile Steel Container House Aluminum Profile For Office Building

Product Details:

Place of Origin: China
Brand Name: Fesec
Certification: EN 1090-2-2018; ISO3834
Model Number: office booth

Payment & Shipping Terms:

Minimum Order Quantity: 6 sets
Price: USD3980-4980 per set
Packaging Details: Standard seaworthy Wooden case packing.
Delivery Time: 15-30 work days
Payment Terms: L/C, T/T, D/A
Supply Ability: 1000 Sets per Month
Detailed Product Description
Product Name: Meeting Pods,office Booth, Phone Booth Material:: 1.5~2.5 Thick Aluminum Profile
Ventilation Fan: Speed: 750/1200 RPM Light: 4000K Natural Lighting
Width: 6000mm Depth: 2440mm
Height: 2920mm
High Light:

Prefab Steel Structure Living Container House

,

Prefabricated aluminum profile Container House

,

Luxury Mobile

Prefabricated Luxury Mobile Wooden Steel Structure Living Container House

Specification

Item Materials
Dimension 6000*2440*2920mm
Weight 18000
STEEL FRAME 1.Material: Q235 galvanized steel; thickness, 2.5~4.0mm
2.Support:C100x40x2.0 or C80x40x1.2 purlin
3.Connection: high strength bolt M12*40
4.Surface working: sand blasting, epoxy basic painting 55μm, final vinyl acrylic painting 55μm thick
Top and bottom gray (rust-proof primer, gray finish)
Column: 210x150x2550mm 2.5mm--4pcs
Wall Wall Panel: 75mm thickness glass fiber sandwich panel
ROOF Outside Steel: 0.5mm steel sheet
Keel: C80x40x20x2.0 or C80x40x1.2 steel purline
Insulation Layer: 100mm thickness fiber glass(16kg/m3), Fire-proof level: A
Ceiling: 0.5mm colored-steel +Ceiling aluminum edge
FLOOR Material: Q235 galvanized steel; thickness, 2.5~4.0mm
Keel: C100x50x2.0 or C100x50x1.5 square tube,galvanized steel
Insulation Layer: 100mm thickness fiber glass
Cement floor: 18mm thickness cement particle board
Surface: PVC Floor leather (thickness 2.0mm)
Doors 0.5mm double-sided steel security door ,Size: 970x2070mm 840x2070mm
Lock: high quality press lock
Windows Windows : Plastic steel hollow glass sliding window (usually 2pcs) with screen window and security net
Size: 930x1200mm
Electricity System Double tube fluorescent light (usually 2 pcs)
Distribution board: CE approval (1 pcs)
The lines inside the wall panels
Electrical wire, 2.5mm2 for lighting system, 4mm2 for AC units. copper core
3 sets of 16A five holes universal socket and 1 air conditioning socket
Electrical distribution box + breakers + earth leakage protective device
Others Lift corner piece Rainspout: Φ50PVC pipe and others
Optional 1.Exhaust fan
2. Floor heating: 100mm thickness fiber glass(16kg/m3), Fire-proof level: A
3. Sanitary ware:
Western Close tool: ceramic, with pipes and installation fittings
Urinal: ceramic, with pipes and installation fittings
Wash basin: ceramic, with post, faucet, pipes and installation fittings
Shower head, Shower base, Water mixture
4. Air condition&Office furniture
Packing 6sets in a 40HQ container

Applications

Residential buildings Commercial buildings Institutional buildings Booths
*cabins

*bungalows

*townhouses

*vacation houses

*two-storey houses/villas

*hotels

*resorts

*offices

*showrooms

*4s car shops

*supermarkets

*accommodation

*schools

*hospitals

*medical clinics

*health-care centers

*guardhouses

*public toilets

parking lot kiosks

Advantages compared to ordinary housing

1.Stable structure: The main structure is light steel structure and sandwich panel. They form a stable structure so it can resist 9-11 grade hurricane and 7 grade earthquake.
2. Quick Installation: Convenient to assemble and disassemble. Six skillful Chinese workers can finish installing 100m2 in three days.
3. Flexible layout: The partition wall, window, ceiling, door are optional for clients.
4. Long service life: The components of house can be used repeatedly, so its designed life span can reach up to more than 25 years in normal environment.
5. Environmentally friendly: Almost dry construction which is environmental friendly.
6. Good performance: Water proof, moisture proof, heat insulation and sound insulation.

Prefabricated Luxury Mobile Steel Container House Aluminum Profile For Office Building 0

The main features for container house:
1) It could be widely used as house, office,meeting room,dormitory, storage, shower rooms,guard, toilet,hotel, shop, restaurant, booth, kiosk etc.
2) Several units could be combined and stacked to be a big beautiful building based on customized designs, with inside,outside, stairs, aisles and porch container house.
3)It could be assembled and disassembled by hands, 100% nut-bolt connection, two men could install one set in 2hours.
4)The top and bottom main steel frames were welded separately, upgrade and strengthened panels, door, window, it is of high firmness and excellent performance of waterproof, thermal and sound insulation with long service.

Our Advantages

1) Stand heavy rain

2) Suitable for Southeast Asia market

3) Life Spain: around 15 to 20 years. we can guarantee for 10 years.

4) Fire Proof: B Level

5) Thermal Conductivity: 0.042 m2·K/W

6) Wind Load: Wind speed 120 Km/h

7) Earthquake Resistance: Up to Richter 8 or as required

Frequently Asked Questions

1.Q: Could you please design a new and unique prefab house for me?
A: Absolutely! We are able to provide you with not only construction scheme, but landscape design! One-stop service is our outstanding superiority with no doubt.

2.Q: What should I provide to build a prefab house?
A: So easy! Sketch drawing would be a better reference for us. However, you will never mind if you don’t have any. Simply notify us your requirements, such as the area, usage and the stories of the house. Before long, you’ll possess an amazing design.

3.Q: How could I ensure the cost of building a prefab house?
A: Firstly, the designing scheme should be accepted. Then, the kinds of building materials should be confirmed since different types and qualities make various prices. After that, we will send you a detailed quotation.

4.Q: How Long does it take to build a light steel prefab house?
A: It depends on the size of the house. Generally, one 50 square meter house five workers 1-3days finished installation, save manpower and time

5.Q: Is it difficult to build a prefab house?
A: Totally not, you can build the house independently according to the construction drawings as long as you know how to use an electric tool.

6.Q: Does this kind of house can only be used in residential buildings?
A: Absolutely not. It can be used in all kinds of buildings, such as hotel, office, school, entertainment club, light industrial workshop, etc.
