Product Details:
Payment & Shipping Terms:
|
Material: | Steel | Grade: | SY295, SY390, Q345P,S355GP Etc |
---|---|---|---|
Connection: | Larssen Interlock | Application: | Beach Protection, Ground Slope Stablization |
Tolerance: | +/-5% | Color: | Original Or Painted |
Turn Around Time: | 35 Days | Width: | 600mm,700mm,750mm,840mm,900mm Or Customized |
Height: | 130mm,150mm,250mm,280mm,310mm,350mm Or Customized | Thickness: | 3.5mm,4mm,5mm,6mm,7mm,8mm,9mm Or Customized |
High Light: | omega steel sheet piling,beach erosion protection steel sheet piling,road slope stabilization steel sheet piling |
Omega-type Sheet Piles
OMEGA PILES have higher stiffness compared to U-type sheet piles, as the interlocks are at the outermost part of the sheet piles, as far away from the neutral axis as possible.
Features and advantages
*Suitable for locations where space is restricted, as sheet piles are installed along the same line,
*Can be produced in wider sections than the U-type sheet piles,
*Light weight and cost effective,
*Sizes available: from 4-16 mm thick, 600-1,600 mm wide, and section modulus from 183-4,600 cm3/m,
*Can be produced as per customer’s own design.
Steel Grade: S275,S355,S390,S430,SY295,SY390, etc.
Standard : EN10248, ASTM A-328,JIS A 5523 , JIS A 5528
Detailed Product Images
Applications
Omega sheet pile is often used for beach erosion protection, used to stablize ground slopes, especially roads, and used to support trenches and other excavated walls and cofferdams. When the height of the wall is less than 3 meters, it is usually cantilevered. However, for larger wall heights, the omega sheet piles usually uses one or more anchors to anchor it.
Hangzhou Famous Steel Engineering Co.,Ltd
Famous is a business unit of KNSN Group. Famous supplies to the global markets a wide variety of premium steel products for foundations : Z type, U type, Omega type, Trench, Flat web sheet piles, HZ combined walls, Tubular combined walls, tie-rods and accessories, in assortment of steel grades and production standards. A wide range of thicknesses and widths and depths are achievable at very moderate prices and committed to be shipped within the stipulated time frame.
If you have interest, please contact us and tell us about your project by email or phone. We are happy to talk about our capabilities and solutions for your requirement.
