Product Details:
Payment & Shipping Terms:
|
Steel Thick: | 0.9mm | Thickness: | 120mm |
---|---|---|---|
Steel Color: | Grey | Effective Width: | 1150mm |
Length: | 10m | Density: | 42kg |
High Light: | metal roof sheet,corrugated metal roofing sheets |
Features :
light and durable
easy installation
hot & sound insulation
High quality
Working life: More than 20 years
Specifications :
1. Materials : Double color steel + pu(polyurethane ) foam panel (stainless steel or aluminum
also can supply )
2. color steel thickness :0.4mm-1.0mm
3. Total Thickness: 50mm / 75mm / 100mm
4. Width :970mm
5. Length : can be cut as the customer’s requirement
6. Heat conductivity (W / m.k) ≤0.025
7. Compressive strength (kg / cm2) ≥2.0
8. density :30 ~ 60kg/m3 (no deformation under high pressure)
9. Fireproof Grade: B1-class
10. Board face protection : double faced PVC protective film
Sandwich Panel Model No. |
950 |
Effective Width of Sandwich Panel |
950mm |
Steel Sheet Thickness |
0.3 - 0.8mm |
Steel Sheet Color |
RAL standard |
Polyurethane Thickness |
30 - 150mm |
Polyurethane Density |
35-48kg/m3 |
Sandwich Panel Length |
Cut as customers’ request |
Application :
PU sandwich panel it is widly used as wall/roofing material for steel structure plant, gym,
Supermatet ,commercial and civilian facilitie etc, especially for refrigeration house .
