Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room

China Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room supplier
Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room supplier Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room supplier Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room supplier Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room supplier Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room supplier Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room supplier

Large Image :  Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room

Product Details:

Place of Origin: Mainland of China
Brand Name: FAMOUS
Certification: CE,ISO9001,SASO,SGS
Model Number: 960mm & 1180mm

Payment & Shipping Terms:

Minimum Order Quantity: 1 20'GP
Price: USD 10-20/ square meter
Packaging Details: Standard seaworthy packing
Delivery Time: within 20-30days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 square meters per month
Contact Now
Detailed Product Description
Insulation Material: PU/EPS/PIR/XPS Panel Thickness: 50, 75, 100, 120, 150 , 200 Mm,etc
Density Of PU Panelunit: 38-42 Kg/m3 Surface Material Of PU Panel: PPGI, Stainless Steel,Color Steel Sheet,Galvanized Steel Coils,etc
Functions: Fresh Keeping ,Frozen, Heat Insulation, Waterproof,Fireproof,etc. Color: White ,Gray, Or Customized,etc
Joint Methods: Cam-lock, Plug-in,etc. Application: Cold Storage Project, Building Materials ,etc.
Length: According To Customers Pressure: ≥0.5MPa



China Provider Bio-Pharma Cold Storage Room Medical Laboratory Freezer Clean Room





1. Quick Refrigeration
2. Long Refreshment Time
3. Imported Condensing Unit and Other parts
4. Top -10 Brand in China

Features:
1. Temperature range: -60 celsius ~ + 20 celsius are all available
2. Size: Customization
3. Functions: Fresh-keep, freezing, quick-freezing, fire-proof, explosion-proof, air-conditioning are all available
4. Good performance, low noise and high reliability
5. World renowned brand refrigeration accessories, guarantee long use cycle.
6. The automatic high precision digital controller is easy to operate with high efficiency.
7. Adjustable indoor temperature saves electricity up to 30%

Components:
Condensing unit: Bitzer, Copeland, Maneurop, Fusheng
Evaporator: Laiao brand
Insulation Panel: PU, EPS
Other accessories: World-famous brands, like Danfoss, Castle, Every Control, Siemens, LG

Advantages:
Laiao cold room was honored with "Top-10 brands in China"
Laiao is one of the few companies in China which have "First-grade Qualification for Cold Room Installation".

Application fields: Biology, industry, military, food, florist, farming, medicine, logistics, hospitality, and food processing.

Exported country: Global Market





Customized cold room/ storage

Dimension Length (m) *Width (m)*Height (m)
Panel Polyurethane insulation panel,38-42kg/m3, fire retardant B2,PIR
Foaming material BASF
Panel thickness 50mm,75mm,100mm,120mm,150mm,200mm
Steel cover embossed aluminum,painted galvanized steel,stainless steel,PVC stell
Panel connection cam lock type, use hexagonal key to assemble and disassemble
Type of door hinge door, convex door,manual sliding door,electrical sliding door
Temp.of room -60~+20 degree ºC, optional
Purpose of cold room fruit,vegetable,flower etc,frozen food,fish,meat,chicken etc.
Refrigeration unit Bitzer, Copeland, Maneurop, Fusheng etc.
Refrigeration type air cooled / water cooled/evaporative cooled
Fittings all necessary fittings are included, optional
Place to assemble indoor/out door(concrete construction building/steel construction building)
Voltage 220V/50HZ, 220V/60HZ, 380V/50HZ ,440V/60HZoptional



Room size type.

Room size small middle big
volume range <500m3 500m3~5000m3 >5000m3



Tempreture table for reference

cold storage goods tempreture range
processing room 10C
fruit, vegetable, dry food 0C~-5C
medicine, cake, pastry, chemical material 0C~-5C
ice storage room -5~-10C
fish, meat storage -18~-25C
deep freezer -25C~-35C


Compressor type and condenser

compressor type bitzer(Germany) refcomp(italy) copeland(US) manurope(France)
condenser air cooled water cooled evaporating



Panels information

office Foam panel 50mm thickness
processing room 10C 50mm/ 75mm PU
5C 75mm/ 100mm PU
-18C 100mm/ 150mm PU
-25C/ -35C 150mm/200mm PU
panel steel cover SS, PPGI, aluminum,galvanized coils etc



At FASECbuildings, we believe in providing only the best refrigerated warehouse construction services. We operate in the construction of standard cold warehouses and warehouses used for food processing. We believe that your build should be worry-free and hassle-free through the entire sequence.

Every project that FASEC accepts is built to unique specifications and requirements. Many options must be considered when constructing a refrigerated warehouse facility including the best site for the project and any special engineering requirements needed. Our cold storage facility experts can guide you through every step of the building process.

What To Expect
An Energy Efficient Building
Low Long Term Maintenance
Good Looking Building
Space Efficient
Ease of Expansion



When constructing a building designed for pharmacy cold storage, possibly the most important thing to consider is to maintain the perfect temperature and which concrete floor to use. Not all concrete floors are created equal and using the wrong one can lead to trouble and unnecessary expense. With our knowledge and experience, you will get the best possible concrete floor system to meet your cold storage warehousing needs.

Because so many different things must be considered, construction of pharma cold storage facilities requires an enormous degree of precision and detail. Since we specialize in this type of construction, we know that FASECbuildings is the best choice for all of your cold storage warehousing projects. When you contact us, we will review your plans closely and share our strategy for building your perfect cold storage warehouse.





Bio - Pharma Cold Storage Room Medical Laboratory Freezer Clean Room
